Description
High-quality water hose quick connector is a garden hose quick connect. It is intubation type and has 03/04/06/23mm input cannula diameters. Faster connectors are quick and easy to connect and disconnect. Quick connect is perfect for garden hoses, watering equipment for pressure washers, RVs, campers, faucets, lawn sprinklers, spigots, taps and other garden accessories.
Specifications
| Model | ATO-KJH |
| Fluid | Air/Water |
| Material | Brass |
| Maximum operating pressure | 1.0MPa |
| Operating vacuum pressure | -100kPa |
| Proof pressure | 3.0MPa |
| Ambient and fluid temperature | Air:-5~60°C, Water:0~40°C |
| Tubing material | Nylon, Soft nylon, Polyurethane |
| Tubing O.D. | Φ3, Φ3.2, Φ4, Φ6 |
Quick Connector Details
| Applicable tubing O.D (mm) | Model | Weight (g) | |
| ① | ② | ||
| Ø3 | ATO-KJH03-00 | 1.4 | |
| Ø3.2 | ATO-KJH23-00 | 1.4 | |
| Ø4 | ATO-KJH04-00 | 1.7 | |
| Ø6 | ATO-KJH06-00 | 2.5 | |
| Ø3 | Ø4 | ATO-KJH03-04 | 1.6 |
| Ø3.2 | Ø4 | ATO-KJH23-04 | 1.6 |
| Ø4 | Ø6 | ATO-KJH04-06 | 2.2 |
Tips: Quick connector functions
- Exchange function: pneumatic pressure, hydraulic tools, cylinders, hydraulic cylinders, metal mold-related machinery appurtenances.
- Maintenance function: cooling device of a computer, cylinder of die-casting machine maintenance and repair.
- Testing function: testing of vacuum, pressure resistance, leakage, operation, etc.
- Conveying function: conveying and handling of bolts, nuts and other solids as well as conducting function.
- Filling function: inert gas, nitrogen, PG, carbonic acid.
- Connection function: fixed parts of fishing rods and pocket laser records, connection for mobile work and uses other than fluid transfer.
