Belimo F6100-300SHP+2*GKX24-MFT-X1 2-Way 4″ Inch Butterfly Valve, ANSI Class 300, Cv 451 + Dual Electronic Fail-Safe Actuator, 24VAC/DC, Programmable (2-10VDC Default) Control, 5-Year Warranty

Description

Belimo F6100-300SHP+2*GKX24-MFT-X1 : 2-Way 4″ Inch Butterfly Valve, ANSI Class 300, Cv 451 + Dual Electronic Fail-Safe Actuator, 24VAC/DC, Programmable (2-10VDC Default) Control, 5-Year Warranty

This Belimo butterfly valve assembly provides dependable flow control for chilled water and hot water HVAC hydronic systems. The electronic fail-safe actuator supports modulating control and common building automation sequences. Use the specifications below to confirm pressure class, Cv, voltage, control signal, and enclosure rating before ordering.

Belimo F6100-300SHP Valve Specifications

ANSI Class	300
Pattern	2-way
Cv	451
Fluid	Chilled or hot water, up to 60% glycol, steam
Body Pressure Rating	ANSI Class 300
End Fitting	Flange
Valve Size	4″ [100]



Belimo 2*GKX24-MFT-X1 Valve Actuator Specifications
