ASCO JKH8551G401AC120/60,110/50 – Pilot Valve

Description

Specifications

• Function: 4 way
• Body Material: Aluminum
• Flow (Cv): 0.86 Cv
• Pipe/Port Type and Size: NPT 1/4
• Media: Air, Inert Gas
• Min Operating Pressure (Air): 30 psi
• Max Operating Pressure (Air): 150 psi
• Voltage and Frequency: 110, 120 Volts AC with 50/60 Hz
• Watt Rating: 10.1 W
• Orifice Size: 1/4 in
• Coil Number: 238812-032
• Carton Note: 1/4 X 1/4 4NC ALUM 10.1/H AC
