ASCO EV8316G084VMBDC24/DCD – Pilot Valve

Description

Specifications

• Valve Actuation: Solenoid
• Function: 3 way – 3/2 Normally Closed
• Body Material: Stainless Steel
• Flow (Cv): 4 Cv
• Pipe/Port Type and Size: NPT 1/2
• Media: Air, Inert Gas
• Min Operating Pressure (Air): 15 psi
• Max Operating Pressure (Air): 120 psi
• Min Ambient Temperature: 32°
• Max Ambient Temperature: 140°
• Min Fluid Temperature: 32°
• Max Fluid Temperature: 120°
• Voltage and Frequency: 24 Volts DC
• Watt Rating: 11.6 W
• Orifice Size: 5/8 in
• Coil Class: FT
• Coil Number: 274714-006-D
• Mounting Direction: Any, 18 inch
• Carton Note: 1/2 X 5/8 3NC S.S. 11.6/F DC
• Kit Number: 318401-V
