ASCO EV8316G082VAC120/60,110/50D – Pilot Valve

Description

Specifications

• Valve Actuation: Solenoid
• Function: 3 way – 3/2 Normally Closed
• Body Material: Stainless Steel
• Flow (Cv): 1.5 Cv
• Pipe/Port Type and Size: NPT 3/8
• Media: Air, Inert Gas
• Min Operating Pressure (Air): 15 psi
• Max Operating Pressure (Air): 150 psi
• Min Ambient Temperature: 32°
• Max Ambient Temperature: 125°
• Min Fluid Temperature: 32°
• Max Fluid Temperature: 180°
• Voltage and Frequency: 110, 120 Volts AC with 50/60 Hz
• Watt Rating: 10.1 W
• Holding Current (VA): 25
• Orifice Size: 5/16 in
• Coil Class: FT
• Coil Number: 274614-032-D
• Lead Length: 18 inch, Any
• Carton Note: 3/8 X 5/16 3NC S.S. 10.1/F AC
• Kit Number: 318180-V
