Description
Specifications
- Valve Actuation: Solenoid – Air Pilot
- Function: 3 way – 3/2 Normally Closed
- Body Material: Brass
- Flow (Cv): 1.5 Cv
- Pipe/Port Type and Size: NPT 1/4
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 125°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 180°
- Product Weight: 0 lbs
- Voltage and Frequency: 220 AC with 60 Hz
- Watt Rating: 10.1 W
- Holding Current (VA): 25
- Orifice Size: 5/16 in
- Coil Class: FT
- Coil Number: 238610-054-D
- Lead Length: 18 inch, ANY
- Carton Note: 1/4 X 5/16 3NC BRASS 10.1/F AC
- Kit Number: 318180-V
