Description
Specifications
- Valve Actuation: Solenoid
- Function: 2 way – 2/2 Normally Closed
- Body Material: Brass
- Flow (Cv): 4.4 Cv
- Pipe/Port Type and Size: NPT 3/8
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 140°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 210°
- Product Weight: 0.99 lbs
- Voltage and Frequency: 480 AC, 440 AC with 50/60 Hz
- Watt Rating: 10.1 W
- Orifice Size: 1/2 in
- Coil Class: HT
- Coil Number: 238810-088-D
- Lead Length: Any, 18 inch
- Carton Note: 3/8 X 1/2 2NC BRASS 10.1/H AC
- Kit Number: 323468
