Description
Specifications
- Valve Actuation: Solenoid – Direct Acting
- Function: 2 way – 2/2 Normally Open
- Body Material: Aluminum
- Flow (Cv): 4 Cv
- Pipe/Port Type and Size: NPT 1/2
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 125°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 125°
- Product Weight: 2.29 lbs
- Voltage and Frequency: 12 Volts AC with 60 Hz
- Watt Rating: 10.1 W
- Orifice Size: 3/4 in
- Coil Class: FT
- Coil Number: 238610-001-D
- Lead Length: Any, 18 inch
- Carton Note: 1/2 X 3/4 2NO AL 10.1/F AC
- Kit Number: 302361
