Description
Specifications
- Valve Actuation: Solenoid – Direct Acting
- Function: 2 way – 2/2 Normally Closed
- Body Material: Aluminum
- Flow (Cv): 3.5 Cv
- Pipe/Port Type and Size: NPT 3/8
- Min Operating Pressure (Air): 5 psi
- Max Operating Pressure (Air): 125 psi
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 104°
- Product Weight: 1.3 lbs
- Voltage and Frequency: 12 Volts DC
- Watt Rating: 11.6 W
- Orifice Size: 3/4 in
- Coil Class: F
- Coil Number: 238710-004-D
- Mounting Direction: 18 inch, Any
- Carton Note: 3/8 X 3/4 2NC AL 11.6/F DC
- Kit Number: 302429
