Name: AC Servo Drive for ATO Servo Motor
SKU: ATO-MG1000
Availability: InStock

Description

Features

AC servo drive 220V, 380V for choice. 220V single phase or three phase input, 380V three phase input.
Support modbus RS485 and RS232 communication protocol.
Position, speed, and torque control.
Requires 2500PPR encoder input.
Capable of updating the information of 1000 I/O.

Specifications

Model	ATOMG-1000
Matching Servo Motor Model	ATO-SERVO-40S50 (50W servo motor) ATO-SERVO-40S100 (100W servo motor) ATO-SERVO-150S3000 (3 kW servo motor) ATO-SERVO-150S3500 (3.5 kW servo motor) ATO-SERVO-180S3700 (3.7 kW servo motor) ATO-SERVO-150S3800 (3.8 kW servo motor) ATO-SERVO-180S4500 (4.5 kW servo motor) ATO-SERVO-150S5500 (5.5 kW servo motor) ATO-SERVO-180S7500 (7.5 kW servo motor)
Current of IPM module	20A/30A/50A/75A
Control power supply and main circuit power supply	Single phase or three phase AC 220V for motors below 1.5kW Three phase AC 220V or 380V for motors above 1.5kW Note: Servo drive can be used for 1-phase, but the performance will better if it is supplied via 3-phase)
Environment	Temperature	Working temperature: 0 – 55℃ Storage temperature: -40℃ – 80℃
Humidity	No more than 90% ( without condensation)
Air index	No dust (conductive media such as metal powder, etc.) in the electric cabinet
Control Mode	Position control Speed control Torque control JOG operation Four Internal speed control Internal position control Internal torque control Position & speed control Speed & torque control
External I/O	Servo enable Reset Position deviation reset Pulse, CCW, and CW disabled Position switching Speed selection Zero speed clamping The second reset Extended functions (options) such as orientation and permissible stop, etc.
Encoder Feedback	10000p/r (standard); frequency division permissible (options)
Communication Mode	RS232 (closed) RS485 (closed)
Load Inertia	Less than 5 times the inertia of the motor
Monitoring Function	Speed, current position, command pulse accumulation, position deviation, motor current, operation status, input and output terminals, and Z pulse signal, etc.
Protection Function	Overvoltage, overcurrent, over-speed, and incorrect feedback, etc.
Alarm Function	Alarms (LED flashing; red lamp on) are often given off when the servo operates abnormally.
Gain Adjustment	Gain adjustment can be carried out to match motor performance when the motor operates or stops.
Adaptive Motor	ATO AC servo motors

Tips: How does a servo drive work?
The servo driver adopts digital signal processor (DSP) as the control core, an realize the complex control algorithm, digitization, networking and intelligentialization. The power device generally adopts intelligent power module (IPM) as the driving circuit of the core design. IPM integrated drive circuit with over-voltage and over-current, overheating, undervoltage fault detection and protection circuit. The soft start circuit is also added in the major loop, so as to reduce the impact on thedrive in the start-up process.
First, the power drive unit is rectified by the three-phase full bridge rectifier circuit to input the three-phase electric or municipal power, and the corresponding DC power is obtained. The three-phase power or electric supply after rectifying can drive the AC servo motor through three-phase sine PWM voltage source inverter frequency conversion. The whole process of the power drive unit can be simply described as the process of AC-DC-AC. The main topology of the rectifier unit (AC-DC) is the three-phase full bridge uncontrolled rectifier circuit.
